3/2-way solenoid valve G 1/8" monostable / MF / NO / 580 NL - 1

    3/2-way solenoid valve G 1/8" monostable / MF / NO / 580 NL

    €68.97
    Tax excluded
    AF-2501

    Coil fastening nut NOT included!

    help_outlineAsk about product
    3/2-way solenoid valve G 1/8" monostable / MF / NO / 580 NL

    3/2-way solenoid valve G 1/8" monostable / MF / NO / 580 NL

    I accept privacy policy rules

    Construction:
    • 3/2-way
    Threaded connection:
    • 1/8"
    Flow:
    • 580 NL/min
    Position:
    • NO - open
    Manual override:
    • Screw
    Standard:
    • Standard
    Activity:
    • electr. actuated
    Function:
    • pneum.-mech. spring
    Series:
    • AF
    Last items in stock

    Temperature range: max. +50°C

    Medium: Filtered air 50μm, with or without lubrication, -5°C to +60°C.

    Materials: Membrane: Vulkollan

    Pressure range: max. 10 bar

    AF-2501

    Specific References

    Reference:
    AF-2501
    Threaded connection: 1/8"; Flow: 580 NL/min; Function 2: NO - open; Manual override: Screw; Standard: Standard; Construction: 3/2-way; Activity: electr. actuated; Function: pneum.-mech. spring; Series: AF;
    €68.97
